Powerful 8 Color Rotogravure Printing Machine For Once Through Continuous Printing 1250 MM

Powerful 8 Color Rotogravure Printing Machine For Once Through Continuous Printing 1250 MM

  • High Light

    Flexo Printing Machinery

    ,

    Flexo Printing equipment

  • Max. Printing Size
    1200x1100 MM
  • Non Woven Fabric Roller Width
    1250 MM
  • Non Woven Fabric Thickness
    45-100 GSM
  • Max Diameter Of Rolls
    800 MM
  • Printing Speed
    500-1100 M/H
  • Power Supply
    380V 3P4N 28KW
  • Overall Size
    14500X2200X2200 MM
  • Weight
    7000 KG
  • Place of Origin
    China Mainland
  • Brand Name
    OUNUO/ALLWELL
  • Certification
    CE
  • Model Number
    NWF1400 II
  • Minimum Order Quantity
    1 SET
  • Price
    USD78,000.00/Set
  • Packaging Details
    Shrink film and wooden case packing
  • Delivery Time
    20 days
  • Payment Terms
    T/T,L/C at sight
  • Supply Ability
    50 set/month

Powerful 8 Color Rotogravure Printing Machine For Once Through Continuous Printing 1250 MM

Latest High Speed AZJ-81050A 8 Color Rotogravure Printing Machine With CE

8 Color Rotogravure Printing Machine​ Application

AZJ-81050A 8 Color Rotogravure Printing Machine

This machine is suitable for multi-color once-through continuous printing for such roll film materials with excellent printing performance asBopp film, pet,  pvc, pe, aliminum foil, paper, etc.





Main Technical Variables

Type

AZJ-81050A

ONL-XB800

More Wide Can Be Customized

Fabric Thickness

35-100GSM

35-100GSM

More thin or thick tell us please

Loop Handle Thickness

60-120GSM

60-120GSM



Power supply

220v 50Hz

220V 50Hz

Can change according your factory

Total power

18KW

22KW



Overall size

12000X2600X2000MM

12000X2700X2000MM







Powerful 8 Color Rotogravure Printing Machine For Once Through Continuous Printing 1250 MM 0 Powerful 8 Color Rotogravure Printing Machine For Once Through Continuous Printing 1250 MM 1

BOPP Film

Rotogravure Printing Sample





Powerful 8 Color Rotogravure Printing Machine For Once Through Continuous Printing 1250 MM 2

Feeding Part

1. Rotate Rack in station wall,make sure the accuracy of Processes and installation
2. Double-armed and double station are rotational turret type unwinding
3. Closed-loop tension , PLC automatic control
4. Double-shaft of unwinding use double vector motor independent driving.
5. A motor driving to rotate the turret turn both directions

Printing Unit (8 sets)

1. Separately station structure , easy for disassembling and installation

2. Plate cylinder is fixed by shaft-less air chuck for plate cylinder changing high efficiency
3. Impressing structure of Roller move by swing arm type synergy with a guide roller , make sure the web is changed in Min.when impressing roller is raised or lowered .
4. The adjustment of Single side type for adjusting roller
5. doctor blade movement by independent reduction motor .

Powerful 8 Color Rotogravure Printing Machine For Once Through Continuous Printing 1250 MM 3
Powerful 8 Color Rotogravure Printing Machine For Once Through Continuous Printing 1250 MM 4

Rewinding Part

1. Rotate Rack in station wall,make sure the accuracy of Processes and installation.
2. Double-armed and double station are rotational turret type rewinding.
3. A motor driving to rotate the turret turn both directions
4. Closed-loop Tension, PLC automatic control.

Powerful 8 Color Rotogravure Printing Machine For Once Through Continuous Printing 1250 MM 5
