Product Details:

Place of Origin: Zhejiang
Brand Name: OUNUO
Certification: CE
Model Number: ONL-C700

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Packaging Details: Shrink film and wooden case packing
Delivery Time: 30 days
Payment Terms: T/T,L/C at sight
Supply Ability: 40 set/month
Contact Now
Detailed Product Description
Machine Type: Cutting And Sewing Machinery Certification: CE/ISO9001:2008
Bag Processing: Ultrasonic Sealing Computerized: Yes
Bag Type: Non Woven Bag Warranty: One Year


Shopping Bag Non Woven Bag Making Machine Single Phase with Ultrasonic





Machine Specification:


700Model
Non woven bagFlat bagHandle bagT-shirt bagBox bag
Non wove bag length(mm)100-800100-800100-800100-800
Non woven bag width(mm)100-580100-580100-580100-580
Bag making speed(pcs/min)20-10020-8020-8020-60
Non woven fabric thickness(G/M2)30-10030-10030-10030-100
Rewinding material width1300mm
Machine weight2500kg
Power Supply220V, 50HZ, Single Phase
Total Power21kw
Overall Dimension11000*1950*1800
Air compressor10.2kw
Handle sealing part6 Set Top quality ultrasonic
Loop handle length400-600mm
Loop handle Width250-300mm
Diameter800mm
Handle loop fabric Weight60-120gsm




Machinery Advantage:

1. Ultrasonic device to seal bags in good quality
2. Computer control, automatic feeding, automatic counting, automatic stopping.
3. Easy to operate and strong sealing effective

4. Photocell to track the color
5. Equipped with servo motor
6. Equipped auto pneumatic punching device

7.Equipped with tension control device.
8. Machine has got CE Certification, SGS Certification, company has obation ISO9001:2008 certification


Machinery Features:

Automatic non woven bag making machine with two stepper motor for D-cut bag is the newest and lastest product we reseached , it can sealing the bag handle automatic, no need sepearate handle sealing machine, the sped is fast, speed can reach 60-100pcs/min, it's an idea equipment to make the non woven sealing bag.

Machine Main parameters:

1. One set computer with touch-screen system.
2. One the programmable controller.
3. Six sets of ultrasonic system.
4. Traction inverter to control the main motor

5. Micro-motor four.
6. Two sets of step motors.

7. High quality ultrsonic sealing device from Germany to make sure the bag qulaity

Applications:

1-non woven hadle bag
2-non woven D-cut bag
3-non woven box bag with handle
4-non woven T-shirt bag
5-non woven shoes bag
6-non woven laminating bag



Our Advantage and Service:

1.we have 8 senior engineers service in many countries, all the year round, with our after-sales office in countries.my machines can be monitored via Internet, solve customer requirements immediately2.Our machines have one year guarantee and warranty, life-long maintenance.
3.Has many machines can be monitored via the Internet, solve customer requirements in a timely manner.
4.Has several senior,continuous innovation and reform, in order to ensure the quality of mechanical stability.
5.According to each customer different request,we provide individuation and specialization machine solution. Make sure you spend less money, to get quality and suitable machine.
6.we always focus on non woven bag making machine and relevant machine R&D since our company foundation.
