AW-1600S/2400S/3200S Single S Spunbond Non Woven Fabric Making Machine
AW-1600S/2400S/3200S Single S Spunbond Non Woven Fabric Making Machine
Product Description
| ITEM | EFFECTIVE WIDTH | GSM | ANNUAL OUTPUT | EMBOSSING mPATTERN |
| S | 1600mm | 8-200 | 1500T | Diamond, oval, cross and line |
| S | 2400mm | 8-200 | 2400T | Diamond, oval, cross and line |
| S | 3200mm | 8-200 | 3000T | Diamond, oval, cross and line |
| SS | 1600mm | 10-200 | 2500T | Diamond, oval, cross and line |
| SS | 2400mm | 10-200 | 3300T | Diamond, oval, cross and line |
| SS | 3200mm | 10-200 | 5000T | Diamond, oval, cross and line |
| SMS | 1600mm | 15-200 | 2750T | Diamond and oval |
| SMS | 2400mm | 15-200 | 3630T | Diamond and oval |
| SMS | 3200mm | 15-200 | 5500T | Diamond and oval |
Technical Advantages
1) The whole line is well-structured and easy to operate.
2) The whole line is highly automated.
3) Control elements are of well-know make, high performance and reliable technologies.
4) The whole line are controlled by PLC and operated with touch-screen.
5) The allocation of the main frame and auxiliary equipment can be special designed and adjusted according to customers requirement.
| Raw material specification | ||
| Item | Unit | Technical index |
| Melting index | g/10min | 27-35 |
| Melting point | ℃ | 162-165 |
| Density | G/cm³ | 0.90-0.91 |
| Molecular weight distribution | mw/mn | <=4 |
| Content of grey | PPm | <=250 |
| No equal normality | 5 | <=3.5 |
| Content of water | % | <0.05 |
| Stretch strength | Mpa | >=31 |
Allwell Machinery, as a professional manufacturer of spunbonded PP non woven fabric line, non woven bag making machine, non woven printing machine, soft handle sealing machine and relevant equipment, has an area of 13,000 square meters and 130 on-the-job employees.
We start from a smart factory since 2006. We keep innovating and upgrading equipment to make non woven bag more attractive and durables. 2012-2013, we innovated the first set of one time forming laminated non woven box bag making machine all of the world and get successfully market. The products and services now cover more than 80 countries.
Today, we are adhearing energy saving, efficient, environmental idea to be the leader of non woven bag making industry. We have a great dream and responsibility to provide solution for the intelligent bag making industry.
Our products are sold all over the world, you can rest assured.
