Fabric Non Woven Screen Printing Machine , Bags Label Printing Machinery
This Two color non-woven fabric screen printing machine is developed in 2011. The material is non-woven fabric roll. It can print 2 colors each time. The line composition is Feeding part, First Printer, First IR Dryer, Second Printer, Second IR Dryer and Collecting Part. Water based ink is suited for shopping bags.
It's the upgrade version of single color printing machine. The difference is this two color machine has higher precision. It's a good solution for bags with more than 2 colors. It can make sure the mesh precision.
Single color printing machine can print second or third time, but it has not same effect as two color printing machine. Both machines have photocell, single color printing machine has one for read mark and stop fabric after printing, two color machine has 2 photocells, one is after first printing, the other is after first drying and before second printing.
Performance and Features:
1. Automatic feeding printing,drying and collecting.Save labors and overcome restraints caused by weather conditions.
2. With Balanced pressure,with high ink thickness.Suitable for printing on high-quality non-woven products.
3. Applied to various sizes of printing screen frames.
4. Big-size printing area to print multiply layouts.Improve work efficiency.
5. Before and after full page printing,effective space between images can be reduced to
minimum 1 cm.Effectively reduce the material waste.
6. High precision of printing controlled by servo motor.
7. Connected with non-woven bag making machine to produce the bag automatically.Greatly improve work efficiency.
Main technical parameters:
Model |
FB-NWF12010I |
Max.Printing Size |
1200×1100mm |
Nonwoven Fabric Rolls Width |
1250mm |
Nonwoven Fabric Thickness |
45g/m²~100g/m² |
Max.Diameter of Rolls |
800mm |
Printing Speed |
500-1100m/h |
Voltage&Total Power |
380V 3P4N 24Kw |
Machine Size |
10500×1800×1720mm |
Basic Structure |
Feeding Part+Printing Part+Drying Part+Collegting Part |
Weight |
2000kg |
