Plastic Film Automatic Slitting Machine / PET Materials Slitting Rewinding Machine

Plastic Film Automatic Slitting Machine / PET Materials Slitting Rewinding Machine

  • High Light

    slitter rewinder machine

    ,

    paper slitter rewinder machine

  • Type
    Slitting Machine
  • Condition
    New
  • Warranty
    One Year
  • PLC Control
    Optional
  • Power
    3.75kw
  • Voltage
    3 Phase 380 V 50Hz
  • Place of Origin
    CHINA
  • Brand Name
    OUNUO
  • Certification
    CE ISO9001:2000
  • Model Number
    ONL-1800
  • Minimum Order Quantity
    1 SET
  • Packaging Details
    WOODEN CASE PACKING
  • Delivery Time
    20 DAYS
  • Payment Terms
    T/T ,L/C
  • Supply Ability
    60SET/MONTH

Plastic Film Automatic Slitting Machine / PET Materials Slitting Rewinding Machine



Plastic Film Automatic Slitting Machine / PET Materials Slitting Rewinding Machine



1. Application


This machine is suitable for separating and cutting such various roll materials as BOPP, PET, CPP, CPE, PVC, aluminum foil and paper, etc. And can cut edge, separate and cut material according to different requirements during production.



2.Feature


2.1The machine is a kind of vertical separating and cutting machine, rolling and releasing can be in front of or at the back of the machine.
2.2Independent master control screen, more flexible and even easier operation.
2.3 Automatic deviation-rectifying of releasing, photoelectric eye is suitable for tracking the edge and color of transparent material.
2.4 Releasing tension adopts magnetic powder clutch control.
2.5 Rolling adopts magnetic clutch control.
2.6 Automatic slitter edge blowing-inhaling device.
2.7 Automatic meter counting of material moving length.



3.Main Technical Specification



Model

ONL-1100

ONL-1300

Max. diameter of roll material

600mm

600mm

Max width or roll material

1100mm

1300mm

Paper inner diameter

76mm

76mm

Width of roll material slitting

20-1100mm

20-1300mm

Machine speed

160m/min

160m/mm

Slitting speed

150m/min

150m/min

Max rewind diameter

450mm

450mm

Accurate of adjustment

±0.5mm

±0.5mm

Total power

3kw

3.5kw

Weight

1500kg

1800kg

Overall size

2.5×1.2×1.4m

2.5×1.4×1.4m
