Automatic Good After-sale Shopping Bag Making Machine For Non Woven D-Cut Bag 120pcs/min

Automatic Good After-sale Shopping Bag Making Machine For Non Woven D-Cut Bag 120pcs/min

  • High Light

    non woven fabric bag making machine


    shopping bag making machine


    21KW Automatic Shopping Bag Making Machine

  • Operation
    Computer Touch Screen
  • Welding
  • Warranty
    One Year
  • After Sale Service
    Engineer Available To Overseas Supporting
  • Fully Automatic
  • Total Power
  • Material
    Non-woven Fabric
  • After-sales
    Engineers Available To Service Machinery Overseas.
  • Place of Origin
  • Brand Name
  • Certification
  • Model Number
  • Minimum Order Quantity
    1 SET
  • Price
  • Packaging Details
    Shrink film and wooden case packing
  • Delivery Time
    30 days
  • Payment Terms
    T/T,L/C at sight
  • Supply Ability

Automatic Good After-sale Shopping Bag Making Machine For Non Woven D-Cut Bag 120pcs/min


Welding Automatic Shopping Bag Making Machine For Non Woven D-Cut Bag



Machinery Advantage:


1. Ultrasonic device to seal bags in good quality
2. Computer control, automatic feeding, automatic counting, automatic stopping.
3. Easy to operate and strong sealing effective

4. Photocell to track the color
5. Equipped with servo motor
6. Equipped auto pneumatic punching device

7.Equipped with tension control device.

8. Machine has got CE Certification, SGS Certification, company has obation ISO9001:2008 certification



Machinery Features:


Automatic non woven bag making machine with two stepper motor for D-cut bag is the newest and lastest product we reseached , it can sealing the bag handle automatic, no need sepearate handle sealing machine, the sped is fast, speed can reach 60-100pcs/min, it's an idea equipment to make the non woven sealing bag.




Machine Main parameters:


1. One set computer with touch-screen system.
2. One the programmable controller.
3. Six sets of ultrasonic system.
4. Traction inverter to control the main motor

5. Micro-motor four.
6. Two sets of step motors.

7. High quality ultrasonic sealing device from Germany to make sure the bag quality.



Machine Specification:


Non woven bag Flat bag Handle bag T-shirt bag Box bag
Non wove bag length(mm) 100-800 100-800 100-800 100-800
Non woven bag width(mm) 100-580 100-580 100-580 100-580
Bag making speed(pcs/min) 20-100 20-80 20-80 20-60
Non woven fabric thickness(G/M2) 30-100 30-100 30-100 30-100
Rewinding material width 1300mm
Machine weight 2500kg
Power Supply 220V, 50HZ, Single Phase
Total Power 21kw
Overall Dimension 11000*1950*1800
Air compressor 10.2kw
Handle sealing part 6 Set Top quality ultrasonic
Loop handle length 400-600mm
Loop handle Width 250-300mm
Diameter 800mm
Handle loop fabric Weight 60-120gsm





nonwoven d-cut bag usually for cloth packing and shoes packing
non woven t-shirt bag  for supermarket shopping bag
non woven shoes bag for little gift packing,banana packing
non woven laminating bag for high level packing



Our Advantage and Service:


1.we have 8 senior engineers service in many countries, all the year round, with our after-sales office in countries.my machines can be monitored via Internet, solve customer requirements immediately2.Our machines have one year guarantee and warranty, life-long maintenance.

3.Has many machines can be monitored via the Internet, solve customer requirements in a timely manner.

4.Has several senior,continuous innovation and reform, in order to ensure the quality of mechanical stability.

5.According to each customer different request,we provide individuation and specialization machine solution. Make sure you spend less money, to get quality and suitable machine.

6.we always focus on non woven bag making machine and relevant machine R&D since our company foundation.
