Laiminated Non Woven Bag / Shopping bag 6 Color Rotogravure Printing Machine
Application:
This machine is suitable for BOPP, PET,PE, CPP, PVC and combined film and paper with same properties.
Features:
1,Seven motor synchronization speed control; PLC system
2,Picture Inspection
3,Auto-register and Per-register system
4,Non-stop Auto Material exchange
5,place Swim Arm Tension Control
6,2 place per-dry heating & assistant dry hearting at the unwinding and rewinding part
7,Shaft-less air cylinder device
8.PU rubber roller
Technical Parameters:
NOTE: The specification is based on 6 colors
Model |
ONLY-61200 |
Web width |
1200mm |
Printing speed |
max200m/min |
Print cylinder diameter |
100-350mm |
Rolling material diameter. |
600mm |
Print cylinder cross adjustable |
20mm |
Print cylinder longitudinal adjustable |
1M |
Registering accuracy |
±0.12mm |
Total power |
100kw |
Weight |
40000kg |
Overall dimensions(L×W×H)(mm) |
12800*3200*2800mm |
Winder device: Unwinder and rewinder is featured by the independent driver rotary double-post. The printing materials is fastened by the air shaft, it is safe and reliable, Auto splicing in high-speed. |
Cylinder loading system: Shaft-less for the time-saving and conveniency. |
Color register system: Vertical automatic register and pre-register device, improve accuracy of registration., |
Doctor Blade system: The movement of doctor blade is on the double-shaft by the independent electric motor. |
Drying system: Enclosed air circulatory heating oven, Outlay electrical heater and automatic temperature controller |
Machine Control system: Winder , in-feet and out-feet use import PLC control seven AC vector converter motors and Four closed-loop tension control system, the main electronic and Pneumatic part are imported. |
The printing bag samples:
The machine details:
